Technical Data/Specs
Spectrophotometer microvolume mode
Minimum sample size: 0.5 µl
Pathlength: 0.5 mm (auto ranging to 0.02 mm)
Light source: Pulsed Xenon flash lamp
Detector type: 2,048 element CCD
Wavelength range: 190-840 nm
Wavelength accuracy: 0.5 nm
Spectral resolution: 1.5 nm (FWHM at Hg 253.7 nm)
Absorbance precision: 0.015 AU (1 cm), or 1%, whichever is greater
Absorbance accuracy: 1.5% at 0.75 AU at 260 nm
Absorbance range: 0.015 – 750 (1 cm equivalent)
Detection limit: 0.04 mg/ml BSA; 0.75 ng/µl dsDNA
Maximum concentration: 1,125 mg/ml BSA; 37,500 ng/µl dsDNA
Fluorometer mode
Light sources: UV LED (~375 nm), Blue LED (~470 nm), Green LED (~525 nm), Red LED (~635 nm)
Excitation filters: UV: 361-389 nm, Blue: 442-497 nm, Green: 490-558 nm, Red: 613-662 nm
Emission filters: 435-485 nm, 514-567 nm, 565-650 nm, 665-740 nm
Detectors: Photodiode, detection range 300-1,000 nm
Tube type: 0.5 ml Real-Time thin-wall PCR tube (polypropylene)
